Technical Specifications
UDIMM for ASRock Rack W680D4U-2L2T / W680D4U
Module Density: 8GB
Form Factor: UDIMM
Technology Speed: DDR5 5600MHz PC5-44800
Rank: 1Rx8
Voltage: 1.1V
ECC: Non-ECC
Buffered: Unbuffered
Compatible With: ASRock Rack - W680D4U-2L2T / W680D4U
Compatible Machines: ASRock Rack W680D4U-2L2T, ASRock Rack W680D4U
ASRock Rack W680D4U-2L2T / W680D4U
The ASRock Rack W680D4U-2L2T / W680D4U supports 4 slots of upgradable memory, with a maximum capacity of 192GB. It is compatible with our UDIMM modules for high-performance operation.
NEMIX RAM memory upgrades for the ASRock Rack W680D4U-2L2T / W680D4U are backed by a lifetime replacement warranty.
Our modules are researched, matched, and compatibility-tested using top-tier components from leading suppliers such as Samsung, Micron, and Hynix, ensuring compliance with
industry standards like JEDEC and CE requirements.
ALTERNATE CONFIGURATION SOLUTIONS
Also available for this machine
Memory speed and module type are not interchangeable — choose the page that matches your system.
Description
NEMIX RAM memory upgrades for the ASRock Rack W680D4U-2L2T / W680D4U motherboards: Non-ECC Unbuffered (UDIMM) modules from 8GB to 48GB, available at DDR5 5600MHz PC5-44800, selected as drop-in, compatibility-tested replacements. These boards each take a single Intel Core 14th, 13th or 12th Gen (LGA 1700) processor with 4 DDR5 DIMM slots (two DIMMs per channel), supporting up to 192GB of memory with UDIMM modules up to 48GB each. ASRock Rack rates the platform at DDR5-4400 with one module per channel and 4000 or 3600 MT/s with both slots of a channel populated; JEDEC DDR5-5600 modules clock down to the supported speed. ASRock Rack positions the micro-ATX boards for edge server and general purpose server. The platform accepts either UDIMM or ECC UDIMM modules but the two cannot be mixed: match the type already installed, or see the ECC UDIMM listing for this board. Researched, matched, and compatibility-tested by NEMIX RAM, a US-based server memory specialist since 1993, and backed by a lifetime warranty. Volume, reseller, and B2B pricing available on request — contact our sales team for a quote.
