Technical Specifications
ECC SODIMM for Synology DiskStation DS1522+
Module Density: 8GB
Form Factor: ECC SODIMM
Technology Speed: DDR4 3200MHz PC4-25600
Rank: 1Rx8
Voltage: 1.2V
ECC: ECC
Buffered: Unbuffered
Compatible With: D4ES02-8G, D4ES01-16G, D4ES03-8G, D4ES03-16G
Compatible Machines: Synology DiskStation DS1522+
Synology DiskStation DS1522+
The Synology DiskStation DS1522+ supports 2 slots of upgradable memory, with a maximum capacity of 32GB (2X16GB). It is compatible with our ECC SODIMM modules for high-performance operation.
NEMIX RAM memory upgrades for the Synology DiskStation DS1522+ are backed by a lifetime replacement warranty.
Our modules are researched, matched, and compatibility-tested using top-tier components from leading suppliers such as Samsung, Micron, and Hynix, ensuring compliance with
industry standards like JEDEC and CE requirements.
Description
NEMIX RAM memory upgrades for the Synology DiskStation DS1522+: ECC SODIMM modules from 8GB to 16GB, available at DDR4 3200MHz PC4-25600, selected as drop-in, compatibility-tested replacements. This system runs an AMD Ryzen R1600 processor with 2 memory slots, supporting up to 32GB (2X16GB). The Ryzen R1600 runs memory at up to DDR4-2400; faster modules clock down automatically. 1Rx8/2Rx8, 1.2V, 260-pin, Unbuffered, JEDEC-compliant for stable operation in NAS and storage appliances. Cross-references Synology memory part numbers D4ES02-8G, D4ES01-16G, D4ES03-8G, D4ES03-16G. Researched, matched, and compatibility-tested by NEMIX RAM, a US-based server memory specialist since 1993, and backed by a lifetime warranty. Volume, reseller, and B2B pricing available on request — contact our sales team for a quote.
