Technical Specifications
RDIMM for ASRock WRX90 WS EVO Motherboard
Module Density: 16GB
Form Factor: RDIMM
Technology Speed: DDR5 6400MHz PC5-51200
Rank: 1Rx8
Voltage: 1.1V
ECC: ECC
Buffered: Buffered
Compatible Machines: ASRock WRX90 WS EVO Motherboard
ASRock WRX90 WS EVO Motherboard
The ASRock WRX90 WS EVO Motherboard supports 8 slots of upgradable memory, with a maximum capacity of 2TB. It is compatible with our RDIMM modules for high-performance operation.
NEMIX RAM memory upgrades for the ASRock WRX90 WS EVO Motherboard are backed by a lifetime replacement warranty.
Our modules are researched, matched, and compatibility-tested using top-tier components from leading suppliers such as Samsung, Micron, and Hynix, ensuring compliance with
industry standards like JEDEC and CE requirements.
ALTERNATE CONFIGURATION SOLUTIONS
Also available for this machine
Memory speed and module type are not interchangeable — choose the page that matches your system.
Description
NEMIX RAM memory upgrades for the ASRock WRX90 WS EVO Motherboard: DDR5-6400 PC5-51200 ECC Registered (RDIMM) modules from 16GB to 128GB, sold as single modules and matched kits of up to 8, selected as drop-in, compatibility-tested replacements. 1.1V, 288-pin, JEDEC-compliant.
This is an EEB workstation board with seven PCIe 5.0 x16 slots, dual 10G LAN and a BMC on the AMD WRX90 platform (socket sTR5) for AMD Ryzen Threadripper PRO 9000 WX and 7000 WX processors. It has 8 DDR5 RDIMM slots, one per memory channel, and supports up to 2TB of memory. Threadripper PRO 9000 WX processors run DDR5-6400 RDIMMs at full speed; with a 7000 WX processor these modules run at DDR5-5200. This board takes registered ECC memory (RDIMM) only; unbuffered UDIMMs and non-ECC memory will not work. Install eight identical modules for full eight-channel bandwidth.
Researched, matched, and compatibility-tested by NEMIX RAM, a US-based server memory specialist since 1993, and backed by a lifetime warranty. Purchase orders, net terms, and volume pricing are available for studios, labs and engineering teams; contact our sales team for a quote.
