Technical Specifications
RDIMM for Lenovo ThinkSystem SD520 V4 Multi-Node Server
Module Density: 32GB
Form Factor: RDIMM
Technology Speed: DDR5 6400MHz PC5-51200
Rank: 2Rx8
Voltage: 1.1V
ECC: ECC
Buffered: Buffered
Compatible Machines: Lenovo ThinkSystem SD520 V4 Multi-Node Server
Lenovo ThinkSystem SD520 V4 Multi-Node Server
The Lenovo ThinkSystem SD520 V4 Multi-Node Server supports 8 slots of upgradable memory, with a maximum capacity of 512GB. It is compatible with our RDIMM modules for high-performance operation.
NEMIX RAM memory upgrades for the Lenovo ThinkSystem SD520 V4 Multi-Node Server are backed by a lifetime replacement warranty.
Our modules are researched, matched, and compatibility-tested using top-tier components from leading suppliers such as Samsung, Micron, and Hynix, ensuring compliance with
industry standards like JEDEC and CE requirements.
Description
NEMIX RAM memory upgrades for the Lenovo ThinkSystem SD520 V4 Multi-Node Server: DDR5-6400 PC5-51200 ECC Registered (RDIMM) modules, 32GB to 64GB, sold as single modules and matched kits of up to 8 modules, selected as drop-in, compatibility-tested replacements. 1.1V, 288-pin, JEDEC-compliant.
The ThinkSystem SD520 V4 is a multi-node server for the 2U ThinkSystem D3 V2 chassis, which holds up to four single-socket nodes, each with one Intel Xeon 6700 E-core processor. Each node has 8 DDR5 DIMM slots and supports up to 512GB with 64GB RDIMMs. Slot count and capacity are per node; order one set for each node you upgrade. Lenovo rates it for DDR5-6400 RDIMMs; the Xeon 6710E, 6731E and 6746E run memory at 5600 MT/s, and the 6740E, 6756E, 6766E and 6780E at 6400 MT/s. MRDIMMs are not supported. This server takes DDR5 ECC registered memory (RDIMM); unbuffered UDIMMs will not work, and Lenovo supports one DIMM per channel only, so each node takes exactly 8 modules. Install identical modules in matched sets, in Lenovo's slot order, and use one module size throughout.
Researched, matched, and compatibility-tested by NEMIX RAM, a US-based server memory specialist since 1993, and backed by a lifetime warranty. Purchase orders, net terms, and volume pricing are available for fleet refreshes and data center upgrades of Lenovo ThinkSystem servers; contact our sales team for a quote.
